| MODEL | PH11-3648 PRO | PH11-4048 PRO | PH11-4648 PRO | PH11-5048 PRO | PH11-6048 PRO |
| Rated power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal Battery System Voltage | 48V |
| PV INPUT(DC) |
| Maximum recommended DC power | 4000W | 5000W | 5500W | 6000W | 7000W |
| Nominal DC operating voltage | 360V |
| Maximum DC voltage | 500V |
| MPPT voltage range | 120V~500V |
| Maximum input current | 15A / 15A |
| No.of MPP tracker | 2 |
| Strings per MPP tracker | 1 |
| INVERTER INPUT/ OUTPUT(AC) |
| Nominal AC input/ output power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal input/ output voltage; range | 220/230/240V;180-280V |
| AC grid frequency; range | 50/60Hz; 45~55/55-65Hz |
| Nominal input/ output current | 15.6A | 17.5A | 20A | 21.7A | 26A |
| Maximum input/ output current | 16A | 18.1A | 20.8A | 22.7A | 27.2A |
| Inrush current (spike/duration) | 57.5A/5.2us |
| Total harmonic distortion i(THDi) | <3% |
| Power factor at rated power | 1 |
| Displacement power factor | 0.8leading~0.8lagging |
| Grid type | Single phase |
| BATTERY MODE OUTPUT(AC) |
| Output Rated Power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Nominal output voltage; accuracy range | 230±1% |
| Output ferequency; accuracy range | 50/60Hz (optional)±0.2% |
| Output rated current | 15.6A | 17.5A | 20A | 21.7A | 26A |
| Output waveform | Pure sine wave |
| Peak power | 5400W,10s | 6000W,10s | 6900W,10s | 7500W,10s | 9000W,10s |
| Total harmonic distortion v (linear load) | <3% |
| BATTERY & CHARGER |
| Battery type | Lead-acid battery / Lithium battery |
| Battery voltage | 48V |
| Battery voltage range | 40~60V |
| Charging curve | 3-stage adaptive with maintenance |
| Protection | Over-current protection / Over-temperature protection |
| Maximum charging power | 3600W | 4000W | 4600W | 5000W | 6000W |
| Maximum charging currernt | 75A | 85A | 95A | 100A | 125A |
| EFFICIENCY |
| Maximum efficiency | 97.1% |
| Euro-efficiency | 96.5% |
| MPPT efficiency | 99.8% |
| PROTECTION DEVICES |
| DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current |
| GENERAL |
| Machine Dimension (W*H*D)(mm) | 420*480*215 |
| Package Dimension (W*H*D)(mm) | 610*327*595 |
| N.W(kg) | 30 |
| G.W(kg) | 32 |
| DC connection | H4 / MC4 |
| AC connection | Terminal Block |
| Display | LED+LCD |
| Communication interfaces | Wi-Fi / USB / GPRS / RS485 |
| Ingress protection rating | IP65 |
| Humidity | 0~95% RH(No codensing) |
| Operating temperature range | -20°C+60°C With derating above 45°C |
| Cooling concept | Natural |
| Altitude | <3000m |
| CERTIFICATION & STANDARDS |
| CE-EMC+LVD (EN6100-6-3: 2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011); CE-LVD(EN62477-1:2022); IEC60529; EN50549-1:2019 Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021); C10/C11; UNE217001-2020; UNE217002-2020, NTS-631:2021 (Type A); G98+G99 |
